01Wi-Fi File Transfer & Cluster Printing
No need a USB drive for transferring anymore. Transfer time is 6-10Mbps* and compatible with 2.4G and 5G network.
ELEGOO · Resin Printers
No need for fast resin or ACF release film, it can achieve truly fast printing with the Tilt Release Technology.
1 / 15211.68 x 118.37 x 220.00 mm
Build volume
150 mm / h
Print speed
14 x 19 µm (15120 x 6230)
Resolution
0.01-0.20 mm
Layer height
The machine, crated
With its standard tooling, cabling and starter consumables.
Commissioning on site
Assembled, levelled, calibrated and run to a first accepted part.
Operator handover
A working session with whoever will actually run it, not a manual.
Support after the invoice
Consumables, spares and a person who has seen this machine before.
PFA film. It's the same as the Saturn 2, Saturn 3, Saturn 4 release films.
Yes, it's compatible. However, it is not recommended to use ACF film on this machine. The Saturn 4 Ultra printer utilizes a new tilt-release technology that enables fast printing without the need for ACF. Moreover, it delivers excellent print quality. Addition, ACF film is not helpful for tilt release, only the pull-up type of release will help. Therefore, we recommend using PFA film instead.
Real-Time Monitoring; Empty Build Plate Detection; Time-Lapse Photography; Warp Detection.
You can use this function in CHITUBOX 2.0. Lychee slicer may support this function soon.
Due to the absence of built-in lighting in the camera, the image may appear slightly blurry in low light conditions such as during nighttime or when the room lights are off. This design was made to avoid potential interference caused by additional lighting during the printing process, as well as to mitigate the impact of resin reflections on the camera's AI detection capabilities. Therefore, an internal lighting feature was not included. In addition, we do not recommend adding lighting to the machine on your own.
No, it can only be viewed online in real-time. If necessary, time-lapse photography can be viewed.
It means that the camera is connected and can be viewed in real-time, but it does not indicate that time-lapse photography is enabled. To enable or disable it, you need to set in the Chitu Manager.
No, it's not necessary to keep them open, and closing the Chitu Box software or shutting down the computer will not affect the time-lapse shooting.
Buying the machine is one route. These divisions run this class of equipment as a service, so you brief the outcome instead of operating it.
9 things worth knowing
01No need a USB drive for transferring anymore. Transfer time is 6-10Mbps* and compatible with 2.4G and 5G network.
02Network Management Center，compared to a wide area network (WAN), the data transmission is more secure, stable, and faster. It supports remote sending files, remote control printing, real-time monitoring, and time-lapse photography features.
03When the device is connected to the internet and an update is available, it will prompt the new system version and users can click to upgrade online.
04Quick-release design for effortless access Replaceable vat locks with no fear of resin clogging Dual pour spouts design, makes pouring resin a brief Flip-up design Drip tray design，prevent resin drips on the machine and the working zone.
05Built-in 8G memory for more stable file transfer, faster operation and no delay in printing and loading images PFA release film offers superior release performance, as its non-stick surface prevents the resin from adhering to the film, making it easier to peel off while it also allows for fast printing up to 150mm/h.
06The LCD screen comes with a durable and scratch-resistant protector made of 9H tempered glass, effectively protecting it from scratches and damage.
